N3M-AS High Speed Fully Automatic TTR Slitter| Auto Leader Trailer Station Ribbon Slitting
The N3M-AS stands as the pinnacle of TTR slitting technology. Engineered for medium to large-scale manufacturers and companies in high-labor-cost regions, this model redefines industrial productivity. With a record-breaking speed of 450m/min and a fully automated workflow, the N3M-AS minimizes manual intervention while maximizing high-quality output.
Revolutionary Features
- Industry-Leading Speed: Achieve maximum throughput with a 450m/min slitting speed, designed for high-volume 24/7 operations.
Fully Automatic Leader & Trailer Table: Dramatically reduces cycle time by automating the application of leaders and trailers, ensuring consistent roll finishing every time.
Innovative Ribbon Saving Function: Advanced tension and logic control minimize material waste during start-up and end-of-roll, directly increasing your profit margins.
Automatic Turret & Cross Cutting: Non-stop production is made possible by the 4-shaft turret system and precision automatic cross-cutting, allowing for seamless roll changeovers.
Precision Tooling: Equipped with Magnetic Clip Blade Holders for fast, stable, and accurate width adjustment
450m/min Max Slitting Speed
Fully Automatic Leader Trailer Table
With Ribbon Saving Function
Automatic Turret and Automatic Cross Cutting
| SLITTING WIDTH | 650mm-1010MM |
| SLITTING THICKNESS | 4-20 MICRON |
| UNWIND DIA. | 650MM (MAX) |
| UNWIND CORE I.D. | SHAFTLESS 6 INCH |
| REWINDING DIA. | MAX 150MM(AROUND 1800M) |
| REWINDING WIDTH | MINI 20MM |
| REWINDING CORE I.D | 1 INCH AIR SHAFT AND 1/2 INCH AIR SHAFT |
| SLITTING UNIT | RAZOR BLADE |
| MECHANICAL SPEED | MAX450M/MIN |
| WORKING SPEED | MAX400M/MIN |
| MACHINE SIZE (REF. ONLY): | 2500MM*1150MM*1900MM |
| MACHINE FRAME THICKNESS: | 40MM |
* Other specifications are offered at request.
