POS Roll Slitter Rewinder CP-S1100AW
250m/min High Speed Thermal Paper/Cash Register Paper Slitter Rewinder
Application:
CP-S1100A W is a semi automatic thermal paper slitting machine for producing the rolls of Thermal Paper, Fax Paper, Cash Register Paper, POS Paper, Computer Bill, Medical Record Paper, ATM Receipt, Lottery and so on.
Basic specification:
| Model | CP-S1100A W |
| SLITTING LAYER | SINGLELAYER |
| SLITTING WIDTH | 1100MM |
| SLITTING THICKNESS | 40-120GR/M2 |
| UNWINDING DIAMETER | 1000MM |
| UNWINDING TYPE | AIR SHAFT |
| UNWINDING CORE SIZE | 3 INCH |
| UNWINDING BRAKE TYPE | MAGNETIC POWDER BRAKE |
| REWINDING WIDTH | 30MM(MIN.) |
| REWINDING DIAMETER | 30-200MM (MAX.) |
| REWINDING SHAFT | 10-25MM |
| SLITTING UNIT | 10PCS CIRCLE BLADE |
| WALL THICKNESS | 38MM |
| AUTO CORE LOADING | |
| SHAFT LENGTH | 1100MM |
| SHAFT SIZE | 8-50MM |
| WORKING SPEED | 100PCS/MIN (MAX) |
| MECHANICAL SPEED | 260M/MIN (MAX.) |
| WORKING SPEED | 250M/MIN (MAX.) |
| POWER SUPPLY | 380V,3PHASES, 50Hz |
| AIR POWER SUPPLY | 0.8 Mpa (MINI) |
| MACHINE SIZE | SUBJECT TO THE LINE |
Function Description:
A. AUTO ROLL PUSH OUT
B. AUTO CROSS CUTTING
C. AUTO GLUE SPRAYC.
D. AUTO CORE LOADING
E. AUTO ROLL TURN OVER
B. AUTO CROSS CUTTING
C. AUTO GLUE SPRAYC.
D. AUTO CORE LOADING
E. AUTO ROLL TURN OVER
Installing and trainatiing service:
Air Ticket, Hotel, Food and 100USD/Day/Person Subsidy Provided by Buyers;
At Least Need One Engineer for Installing and Trainning If You Could Provide Chinese Translater;
At Least Need One Engineer for Installing and Trainning If You Could Provide Chinese Translater;
Details:
