Slitting Rewinding Machine Flexible Packaging Material Slitter
The HN1600 PLUS is our latest generation slitter for flexible packaging. Featuring 600m/min speeds, horizontal pressing technology, and closed-loop tension control, which is a high performance slitter widely used in the flexible packaging industry. It can slit the material from 6 microns to 250 microns. Whether the material is BOPP or PE or any others, it can do the same perfect performance.
The HN1600PLUS advanced slitting machine is an upgraded solution designed for higher precision and improved stability in film converting applications. Compared with the standard model, it is equipped with a horizontal direct pressure roller system, ensuring more uniform material contact and enhanced tension consistency, which significantly improves slitting quality and roll finishing.
The HN1600PLUS provides superior performance, better roll tightness, and consistent output for demanding high speed production environments.
Ultra-Wide Material Range:
①Flawless slitting from 6 to 250 microns
②delivering "Perfect Performance" on BOPP, PE, PET, paper, and complex laminates.
Intelligent Closed-Loop Tension:
①Advanced integrated sensors automatically detect
②Self-adjust material tension for total control and roll integrity.
Horizontal Direct Pressure:
①Engineered with a specialized horizontal pressing system to ensure uniform contact
②enhanced tension consistency.
1.Closed-loop Tension Control — Fully automatic, zero manual adjustment.
2.Direct-drive Pressure Rollers — Consistent nip pressure at high speed for superior rewind quality.
3.600 m/min Max Speed — High-speed slitting without quality compromise.
4.Circular & Razor Dual Slitting — One machine, all materials.
5.Reinforced Frame — Greater stability and longer service life.
6.Independent Servo-driven rewind — Faster, more precise rewinding.
7.Next-gen Control System — Intuitive, smooth operation.
8.6–250 μm Thickness Range — Handles all common substrates.
9.Dual-Side Control Panels — Easy operation from both unwind and rewind ends.
10.Exceptional Value — Premium performance, competitive price.
| MODEL | HN1600 PLUS |
| SLITTING THICKNESS | 6 - 250 MICRONS |
| UNWINDING WIDTH | 300 MM TO 1600 MM |
| UNWINDING DIAMETER | MAX 800 MM |
| UNWINDING TYPE | SHAFTLESS 3 INCH AND 6 INCH |
| UNWINDING BRAKE TYPE | MAGNETIC POWDER BRAKE |
| REWINDING WIDTH | MINI 40 MM |
| REWINDING DIAMETER | MAX 600 MM |
| REWINDING SHAFT | FRICTION SHAFTS |
| REWINDING SHAFT SIZE | 3 INCH |
| SLITTING UNIT | RAZOR BLADE |
| WALL THICKNESS | 50 MM |
| MECHANICAL SPEED | MAX 650 M/MIN |
| WORKING SPEED | MAX 600 M/MIN |
| WASTE EDGE UNIT | WASTE EDGE BLOWER |
| LASER POSITION LIGHT | MANUAL LASER |
| METER COUNTER | METER COUNTER |
| POWER SUPPLY | 380V,3PHASES, 50Hz |
| AIR POWER SUPPLY | 0.6 Mpa (MINI) |
| N.W | 4700 KG |
* Other specifications are offered at request.
